| Parameter | Value |
|---|---|
| Temp control | |
| Cooling capacity 400 Vac model¹ | 6 kW |
| COP cooling 400 Vac¹ | 1,7 |
| Flow side A | 15–60 l/min |
| Refrigerant | R134A (non-flammable, A1, allowed in EU for mobile applications, cooling batteries and equipment). R1234yf or R513a on request |
| Max ambient temperature² | 45 °C |
| Min ambient temperature | 10 °C |
| Max A in coolant temperature | 45 °C |
| Min A in coolant temperature | 18 °C |
| Climate control norm or specification | EN 14813-1:2006 |
| Electrical | |
| Primary voltage range 400 Vac model | 400 Vac ±10%, 3-phase, 50–60 Hz ±5% |
| Secondary voltage range | 19–32 Vdc |
| Control system | CANopen, Modbus TCP, remote on/off or self-controlled |
| Power consumption secondary voltage | 0-0,45 kW |
| EMC norm or specification | Designed according to EN50121-3-2:2006 |
| Degree of protection (components protected from water and dust) | IP46 |
| Mechanical | |
| Size | 975 x 505 x 500 mm (L x W X H) |
| Weight | 150 kg |
| Material | Stainless steel |
| Colour | Bare stainless steel |
| Sound level (1 m, non-resonating mounting) | 77 dB(A) |
| Hazard level (according to EN 45545-2:2020+A1:2023) | HL3 exterior |
| Shock and vibration norm or specification | Designed according to EN61373 |
¹ Tested with 23 °C liquid inlet and 18 °C liquid outlet at an outdoor ambient temperature of 35 °C. Cooling duty varies on climatic conditions and altitude, consult DC Airco for specific applications.
² Max 2 hours
